Overview
Televes receiver has a state-of-the-art features, its video decoder can decode
mpeg-2 with a process rate of greater than 15Mbits/s and its stunning audio decoder
can process MPEG-1 layer both I & II version. This Hi-end product has its at most
preferred system. RAM is 2 Mbytes and Flash Memory 1Mbyte with a good graphics rate
of 720x576 on PAL and 720x480 NTSC. This device is cost effective and hi standard.
Specifications
| Video decoder |
MPEG-2 Main Profile @ Main Level
Process rate > 15Mbits/s
Video format 4:3, 16:9 |
| Audio decoder |
MPEG-1 layer I & II (Musicam Audio)
Mono, Dual, Stereo, Joint Stereo |
| System |
RAM 2 Mbyte
Flash memory 1 Mbyte
Graphics 720 x 576 (PAL)
720 x 480 (NTSC) |
| LNB input / tuner |
Connector 2 x “F”
Input frequency 950 - 2150 MHz
LNB powering 13/18V, max. 350 mA
Band switching 22 KHz tone
DiSEqC switching Version 1.0, Tone Burst A/B
Positioner DiSEqC 1.2 / USALS
Demodulation QPSK
Symbol rate 2 - 45 Msps
Covers the C and Ku bands
Covers SCPC and MCPC |
| TV scart |
RGB, CVBS, Audio L/R |
| VCR scart |
CVBS (input/output), Audio L/R (input/output)
|
| Hi-Fi output |
Connector 2 x RCA (L/R) |
| Serial data interface |
Connector 9-pin D-sub
Signals RS232 max.19.2K baud |
| Total connectors |
2 x LNB input (F type)
2 x SCART (TV/VCR)
3 x jacks RCA (VIDEO, AUDIO L/R)
1 x RS232 (9-pin D-sub) |
| Powering |
90 - 260V~, 50/60 Hz |
| Consumption |
30W |
| Size |
280 x 210 x 60 mm |
| Approx. weight |
1.6 Kg |
|
