Used for 3rd Party Integration , send more than 1980 ASCII and/or Hexadecimal Command with 22 ASCII Character Message Length for more flexibility.

2 way communication that can receive up to 99 ASCII,HEX  to do different 20 commands for each message,
Fixed ASCII S-BUS Protocol for integration
Milliseconds Delay optional between each ASCII, HEX command
Easy edit the baud rate from software to integrate with all 3rd part devices,
Suitable for integration for home automation, home theater room, Music system, and industry applications.

Features

• 2 way Fixed S-bus ASCII protocol  from and to RS232
• Support ASCII code editing and Hexadecimal
• send more than 1980 ASCII and/or Hexadecimal
• 22 Characters ASCII length.
• Easy edit the baud rate from software to integrate with all 3rd part devices,
• RS232 interface work in all baud rate: 2400,　4800,　9600,　14400,　19200,　38400,　57600,　115200　bps
• Send And Receive ASCII command
• 2 way communication that can receive up to 99 ASCII,HEX  to do different 20 commands for each message
• Milliseconds Delay optional between each ASCII, HEX command
• Ready integrated with many Music System and Home Technology Brands.

Specifications

Power input: DC 8-32V DC from Bus
Power consumption: 15mA/DC24V
Working temperature: 0℃～+45℃
Working relative humidity: 20% - 90%
Storage temperature: -40℃- +55℃
Storage relative humidity: 10% -  93%
Installation: Standard 35mm rail mounting
Communication: Smart-BUS / RS232

Dimensions

Front: 72×88×66(mm)

Applications

• Home theater, home Automation
• 3rd party integration
• Industry control and communication
