Description
- Desktop or wall mount configuration
- Highest priority access to system
- Maximum 8 connected peak-to peak, each has different priority set by code
- Powered by T-0950, Maximum 100 metres
- Simple operation capable of broadcasting to SINGLE-ZONE CALL MULTI-ZONE CALL All CALL
- Easily operation of All Evacuate, All Clear, Reset and Zone Test
- Self-diagnostics
- AC~220V or DC~24V operation
Specifications
| Power Supply |
24V DC |
| Power Switch |
1x1A |
| Mic Type |
600ohm /10mV |
| Keypad |
99 zones keys, 6 function keys, press 3 seconds to start |
| Volume Adjustment |
-8 to 0dB |
| Alarm Mode Choose |
ALL-EVAC · ALL-CLEAR · TEST-MESSAGE · REST · ALL-CALL · CANCEL |
| Display |
LED indicator for each key |
| Chime Type |
Type 1 |
| Sensitivity |
-62db |
| Frequency Range |
20~2000HZx3db |
| Communication Protocol |
Rs422 2 x db15 IN/OUT |
| Capacity |
8 microphones with in 100 metres |
| Band Rate |
4800bps |
| S/N Rate |
95dB |
| Power Consumption |
5W |
| Dimension(WxHxD) |
280 x 75 x 380mm |
| Surface Material |
Silver Alloy-Aluminium |
| Weight |
3.5 kg |
|
