Description
- Connecting to terminal Amplifiers T-0966
- Display amplifier working status
- BGM channel selection
- BGM volume control
Specifications
| Power Supply |
T-0966 Power 5VDC |
| Alarm Mode Choose |
PG 、Al 、TE 、1-3 MUSIC |
| Channel Control Interface |
S-CL S-DAT S-RST +5V GNDScrew Terminal block |
| Band Rate |
≥40db |
| Connect with T-0966 Distance |
1 pcsT-0966 match with 1 pcsT-0902，MAX.Distance 20M |
| Electrical Volume Control |
0-31class electrical volume(Auto cut to 31 when alarming) |
| Communication Protocol |
Rs422 Screw fixings，IN |
| Power Consumption |
1W |
| Dimension(WxHxD) |
86x86x86 mm |
| Case Material |
ABS Plastic，White |
| Net Weight |
0.5 kg |
|
