Applications
The IP Network Emergency Station is suitable for indoor and outdoor embedded installation. One
touch to call duty officer or a pre-designated target terminal for intercom communication.
Features
- Rectangular embedded design, simple appearance with elegant lines and craft
- One touch for help, a microphone to call duty room, realizing fast connection, simple and quick operation.
- With built-in microphone. Built-in 1W a full-range monitor speaker with clear and loud sounds
- Support hands-free calls and broadcast receiving.
- Support local one line input; one line audio auxiliary output; externally connect to amplifiers.
- Support local emergency button signal.
- Support local electronic door locks and local alarm indicator (select 1 from 2).
- 12V DC power interface.
Specifications
| Model |
T-6703(D1) |
| network interface |
Standard RJ45 input |
| Support Agreement |
TCP/IP, UDP, IGMP(multicast) |
| Audio Format |
MP3/MP2 |
| sampling rate |
8K～48KHz |
| Transfer Rate |
10/100Mbps |
| Audio mode |
16-bit stereo CD sound quality |
| Output frequency |
20Hz～16KHz |
| THD |
≤0.3% |
| Signal to noise ratio |
＞70dB |
| Auxiliary Line Input Level |
400mV dusty-standard voltage wire terminals |
| Audio Output Level |
775mV industry-standard voltage wire terminals |
| Audio Output Level |
1KΩ |
| Operating temperature |
-20℃～+60℃ |
| Operating Humidity |
10%～90% |
| Power |
≤5W |
| Power Supply |
DC12V |
| Dimensions |
240 ×115 ×50mm |
| Weight |
1kg |
|
