4 / 6 / 8 hot-swappable SATA HDD for data storage
-
Maximum storage capacity of more than 4 terabytes
-
Various HDD storage capacities
-
Compatible with full selections of GeoVision accessories
-
GV-Keyboard and GV-IR Remote Control included
-
User-friendly software interface
-
Built-in 4 inputs and 4 outputs
-
Enhanced network security with RSA encryption
Overview
Remove, replace and remain redundant. The GV-Hot Swap DVR System features a powerful
data storage capacity. Thanks to hot swapping external drives, surveillance operations
can stay alert 24/7. Depending on HDD size, the GV-Hot Swap DVR System simultaneously
allows a maximum storage capacity of 4 terabytes. Data storage and service operability
become infinite.
Performance Features
Empowered by GeoVision Surveillance software, the GV-Hot Swap DVR System provides
all critical surveillance features in terms of video quality, compression and recording
rate. Via its network ability, remote access and control of the system facilitate
both management and maintenance. In addition compatibility with a wide range of
GeoVision accessories will cater to any installation needs.
It's all you can store!
Specifications
| |
GV-1480H
|
GV-1240H
|
GV-1120H
|
| Drive Bay |
4 / 6 / 8
|
| CPU |
Intel Pentium 4 3.0 GHz, 800MHz FSB
|
| RAM |
512MB (256MB x 2) Dual Channel |
| Video |
Codec |
Wavelet, MPEG-4, Geo MPEG4, Geo Mpeg4 (ASP), Geo H264
|
| Input |
16 Channels |
8 / 16 Channels |
16 Channels |
| Video Loop Output (Optional) |
16 Channels
|
| Audio |
Compression |
ADPCM / G.723 |
| Input |
16 Channels |
8 / 16 Channels |
16 Channels |
| Display Frames (Max) |
NTSC: 480 FPS / PAL: 400 FPS |
| Recording Frames (NTSC / PAL)
|
480 / 400
(320 x 240) |
240 / 200
(320 x 240) |
120 / 100
(320 x 240) |
| Video Resolution |
NTSC: 720 x 480 / 720 x 480 De-interlace / 720 x 240 / 640
x 480 / 640 x 480 De-interlace / 640 x 240 / 320 x 240 |
| PAL: 720 x 576 / 720 x 576 De-interlace / 720 x 288 / 640
x 480 / 640 x 480 De-interlace / 640 x 240 / 320 x 240 |
| Backup Type |
DVD+R (DL) / DVD-R (DL) / DVD+R / DVD+RW / DVD-R / DVD-RW
/ CD-R / CD-RW |
| Recovery DVD |
Automatic system rebuild |
| Alarm |
Sensor Input |
4 |
| Alarm Output |
4 |
| Connector |
Ethernet |
RJ-45, 10 / 100 / 1000 Mbps |
| VGA Output |
15-pin female D Sub |
| USB 2.0 |
Front: 2 Ports, Rear: 4 Ports |
| Remote Access |
TCP / IP |
| Operating Temp |
0 ~ 50 °C (32 ~ 104 °F) |
| Humidity |
0~80% RH (non-condensing) |
| Dimensions (W x H x D) |
483 x 178 x 528 (mm) - 19 x 7 x 21 (inch)
|
| Hardware Accessory |
GV-Keyboard, GV-IR Remote Control |
| Optional Product |
GV-Hybrid DVR Card / GV-Loop Through Card / GV-IO 12-In
Card / GV-IO 12-Out Card / GV-IO / GV-RELAY / GV-Data Capture V2E /
GV-COM |
| Language |
English / Arabic / Czech / French / German / Hebrew / Hungarian
/ Japanese / Polish / Portuguese (Brazil) / Russian / Spanish / Simplified
Chinese / Traditional Chinese |
|
