- Triplex
- RS-485 Preset Swing IR Remote Controllable
- CD-RW Backup (Option)
- Alarm (4 Input -1 Output )
- 1 and 4 Channels
- Optimized MPEG-4 Compression Codec (Seamless When Forward / Backward
Play)
- Alarm / Log Transmission (Real Time Log Monitoring by Network)
- 4 Loop Through Connector
- Detailed Search (Previous / Next Frame, Pause)
- Recording Environment Setup per Channel (Manual, Schedule, Event Recording)
- PAN / TILT / ZOOM / FOCUS / IRIS
- VCR, Network; via TCP/IP or Cross
- Cable Firmware
- OSD(On Screen Display) Changeable (Optional)
Specifications
| Hardware |
CPU : 32 bit DSP
HDD : Unlimited HDD Space (Range in
HDD x 2)
OS: RTOS |
| Video Input |
4 CH NTSC / PAL |
| Display Speed |
120 (PAL: 100) fps |
| Screen Modes |
1/4 channel Mode |
| Recording Speed |
352 x 240 : 120 / 100
704 x 240 : 60 / 50
704 x 480 : 30 / 25 |
| Monitor Output |
Analog(BNC) / S-Video / Supports
1 Spot Out(BNC) / 4 Loop-through |
| Recording Resolution |
PAL : 352x288,704x288,704x576
NTSC : 352 x 240, 704 x 240, 704 x 480 |
| Recording Methods |
Continuous,
Motion Detection, and Sensor Activated
Recording Schedule: Setting Recording
Schedule per Camera |
| Motion Detection |
Supports the setting of Motion Sensitivity
per Camera |
| Sensor/Camera/Alarm in/out |
MN Mapping |
Audio Input / Output: 4 Input / 1 Output
Sensor / Alarm: 4 Input / 1 Output
VGA Output(Optional) |
1 CH |
| Power |
12 Vdc, 4.5A (Power Supply) |
| Operating Temp and Humidity |
5° ~ 50 °C / 20 ~80 %RH |
| Storage Temp and Humidity |
20° ~ 65 °C / 20 ~95 %RH |
| Remote Transmission |
Remote Pan / Tilt / Zoom / Focus / Iris |
|
