- Compact and advanced design.
- Quick response, low interference, low power consumption and highly
stable.
- Provide different kind of the reading range, up to 8cm (max).
- Interface: ABA T2, Wiegand 26 bit.
- Weather proof, suitable to use in all places.
- Provide LED & Buzzer control input and can fit all controllers.
- The Case sensor provide the controller to guard against remove when
destroy by violence, the warming message will be show.
Specifications
| Communication interface |
T2=ABA Track 2 W=Wiegend 485=RS-485
485 Baud rate …. 19200bps-N-8-1 |
| Input device |
1 (Case sensor) |
| Frequency |
125Khz |
| Indicators |
1 dual of color LED (Power / Status) |
| Reading range |
6-8cm (max) |
| Beep tone |
Buzzer |
| Operating voltage |
DC 12V@200mA |
| Power consumption |
1.5W (max) |
| Temperature |
-10degC – 55degC /
14F -131F |
| Humidity |
20% - 95% (non-condensing) |
| Size |
44W x 95L x 16H(mm) |
| Weight |
55g |
|
